Uponor Smatrix Base Pulse – starter set type S

Uponor Smatrix is ​​a fully integrated control system for radiant heating and cooling. Being intelligent and
able to adapt, Uponor Smatrix is ​​equipped with self-balancing technology, which constantly anticipates and
adjusts the exact amount of energy needed to ensure optimal comfort at all times.

Intelligent automation system for radiant systems

– Up to 4 control units can be connected in one system
– Supply voltage: 230V
– Self-balancing improves energy consumption and comfort
– Electric control
– Up to 6 thermostats and 8 actuators (24V) can be connected on one control unit
– Pump and boiler relays
– Pump and actuator anti-seize function
– Relative humidity control
– Multiple connection possibilities (series / star)
– Supply with 4-wire double-shielded BUS cable
– Communication protocol: RS485 serial BUS
– Maximum actuator input power: 24VAC / 0.2A (0.4A at peak)

– Local access (Wi-Fi) or remote access (requires an internet connection) with the Uponor Smatrix Pulse app (with R-208)
– Temporary wi-fi access point for direct access (if a wi-fi connection is not available (with R-208)
– Integration into a smart home system (Amazon Alexa, Google Home, IFTTT) (with R-208)
– Control of several homes
– Third party access for remote support (requires customer consent) (with R-208)
– Historical trend analysis with the Uponor Smatrix Pulse app (with R-208)
– Hourly programming (with R-208)
– Comfort settings (with R-208)
– Agent temperature check (with R-208)
